Slotted Hole Perforated Sheet for dewatering, draining and sizing with slotted perforated metal, whose elongated openings give more open area than round holes and resist blinding by flat or fibrous particles. 6 sizes listed, with technical drawing and quotation.
Customize the parameters below — every spec field is editable, and the drawing redraws to match the values you choose. Changing the size will snap the other fields to that size's standard values; you can then override any individual value.
Sends the selected values to the quote form below.
Request a Quotation for Slotted Hole Perforated Sheet
Tell us the specification (mesh count / micron / dimensions), material and quantity you need for Slotted Hole Perforated Sheet (DIN 24041 (Lg)) and our team will respond within one business day. Click "Request this configuration" on the drawing above to send the parameters you just chose straight into this form.
Dimensions & Specifications (DIN 24041 (Lg))
Every row below is a starting point for the customizer above — pick any specification row and the drawing will redraw to it.
Slot width (mm)
Slot length (mm)
Bridge (mm)
Open area (%)
Thickness (mm)
Reference standard
0.5
10
1.0
28
0.8
DIN 24041
1.0
12
1.5
33
1.0
DIN 24041
1.5
20
2.0
38
1.2
DIN 24041
2.0
20
2.5
40
1.5
DIN 24041
3.0
25
3.0
43
2.0
DIN 24041
5.0
40
4.0
45
2.0
DIN 24041
Slotted Hole Perforated Sheet (DIN 24041 (Lg)) is used for dewatering, draining and sizing with slotted perforated metal, whose elongated openings give more open area than round holes and resist blinding by flat or fibrous particles.
Slot size: Width × length, e.g. 1 × 10 mm; the width controls retention.
Pattern: Staggered slots for strength, straight rows for maximum open area.
Orientation: State whether slots run along or across the material flow.
Materials
Standard supply is stainless steel 304, stainless steel 316/316L, brass, copper; the material column in the table and the drawing options show the exact grade for each size. Other alloys and finishes can be quoted to your drawing.
Fitting & Care
Run the slots in the direction of material travel so water drains and particles do not catch.
Support long spans — slotted sheet is less stiff across the slots.
Common Mistakes
Turning the sheet 90° in fabrication, so the slots face the wrong way.
Choosing a sheet thinner than the slot width, which tears around the ends.
When Slotted Hole Perforated Sheet Is Not the Right Choice
Not for retaining round particles smaller than the slot width — a round-hole sheet or wire cloth is better.
Slotted Hole Perforated Sheet is stocked and supplied to order in rolls, cut sheets and fabricated pieces. Pricing starts from approximately US$22.00 per unit for standard specifications in stainless steel 304; final pricing depends on specification, alloy, quantity and fabrication (MOQ applies). Submit your exact configuration with the quote form above.
Dewatering, draining and sizing with slotted perforated metal, whose elongated openings give more open area than round holes and resist blinding by flat or fibrous particles.
Why use slotted perforated metal?
Slots give higher open area and drain better than round holes, with less blinding.
What slot sizes are available?
From about 0.5 mm wide upward, in many lengths.
Staggered or straight slots?
Staggered is stronger; straight gives more open area.
What is the specification range of Slotted Hole Perforated Sheet?
The table on this page lists 6 standard specifications for Slotted Hole Perforated Sheet, from 0.5 to 5.0. Specifications outside the table — custom mesh counts, wire diameters, roll widths and fabricated pieces — can be quoted on request.
How do I request a quotation?
Use the parametric drawing on this page to set the exact configuration (specification, material, treatment) and click "Request this configuration" — a specialist from custommetalfilters.com will respond within one business day.
