Aluminum Wire Mesh for screening, filtering and shielding where weight and cost matter more than strength, using woven aluminum cloth that is a third the weight of steel and does not rust. 5 sizes listed, with technical drawing and quotation.
Customize the parameters below — every spec field is editable, and the drawing redraws to match the values you choose. Changing the size will snap the other fields to that size's standard values; you can then override any individual value.
Sends the selected values to the quote form below.
Request a Quotation for Aluminum Wire Mesh
Tell us the specification (mesh count / micron / dimensions), material and quantity you need for Aluminum Wire Mesh (ASTM E2016 / ISO 9044) and our team will respond within one business day. Click "Request this configuration" on the drawing above to send the parameters you just chose straight into this form.
Dimensions & Specifications (ASTM E2016 / ISO 9044)
Every row below is a starting point for the customizer above — pick any specification row and the drawing will redraw to it.
Aluminum Wire Mesh (ASTM E2016 / ISO 9044) is used for screening, filtering and shielding where weight and cost matter more than strength, using woven aluminum cloth that is a third the weight of steel and does not rust.
Also known as: aluminum wire mesh, aluminum mesh, aluminum mesh sheet, aluminium mesh, aluminum screen mesh
Alloy: 5052 for general filters; 5154/5056 for stiffer, more corrosion-resistant screens.
Mesh & wire: 14–18 mesh for vents and grilles; 30–60 mesh for air-filter screens.
Finish: Mill, anodized or powder-coated in black, silver or bronze.
Materials
Standard supply is stainless steel 304; the material column in the table and the drawing options show the exact grade for each size. Other alloys and finishes can be quoted to your drawing.
Fitting & Care
Frame or hem cut edges; aluminum wire is soft and frays if left raw.
Isolate aluminum mesh from copper and brass parts in damp service to prevent galvanic corrosion.
Common Mistakes
Using aluminum in caustic cleaners or high-pH washes, which dissolve it.
Expecting aluminum mesh to resist impact or cutting like stainless steel.
When Aluminum Wire Mesh Is Not the Right Choice
Not for high temperatures above about 200 °C, alkaline cleaning, or security duty — use stainless steel there.
Aluminum Wire Mesh is stocked and supplied to order in rolls, cut sheets and fabricated pieces. Pricing starts from approximately US$3.20 per unit for standard specifications in stainless steel 304; final pricing depends on specification, alloy, quantity and fabrication (MOQ applies). Submit your exact configuration with the quote form above.
Screening, filtering and shielding where weight and cost matter more than strength, using woven aluminum cloth that is a third the weight of steel and does not rust.
Is aluminum wire mesh rust-proof?
Yes — aluminum does not rust; it forms a thin protective oxide layer.
Aluminum or stainless steel mesh?
Aluminum is lighter and cheaper; stainless is stronger, more heat-resistant and survives harsher cleaning.
Which specifications of Aluminum Wire Mesh does custommetalfilters.com supply?
The table on this page lists 5 standard specifications for Aluminum Wire Mesh, from 14-Mesh to 60-Mesh. Specifications outside the table — custom mesh counts, wire diameters, roll widths and fabricated pieces — can be quoted on request.
How do I request a quotation?
Use the parametric drawing on this page to set the exact configuration (specification, material, treatment) and click "Request this configuration" — a specialist from custommetalfilters.com will respond within one business day.
Related Mesh Products
Closely related constructions in Woven Wire Mesh — compare aperture range, open area and cleanability.
