What Is Flattened Expanded Metal Used For?

A flattened expanded aluminum mesh sheet with smooth diamond pattern on a workbench, soft light

Flattened Expanded Metal (DIN 791 / ASTM F1267) is specified where the duty calls for smooth-faced guards, shelves, grilles and filter layers made from expanded metal that is cold-rolled flat after expansion. The sections below cover the typical end-uses by industry, the mesh, micron and material decisions for each, installation practice, and the applications this product type is not suited to.

Typical Applications for Flattened Expanded Metal

Where Flattened Expanded Metal is specified and bought:

  • Shelving & racking: flat expanded shelves in cabinets and carts.
  • Grilles & HVAC: flat filter supports and diffuser faces.
  • Enclosures & partitions: flat, see-through panels.
  • Air filters: expanded aluminum filter layers.

How to Specify Flattened Expanded Metal for Your Application

  • Pattern: SWD × LWD after flattening (the diamond lengthens slightly).
  • Thickness: Flattening reduces thickness by about 10–15 %.
  • Material: Carbon steel, stainless or expanded aluminum.
  • Standard: Quote DIN 791 / ASTM F1267 and the size designation from the table on the product page, plus any value you changed in the technical drawing.

Handling & Installation Practice

  • Frame or band edges, as flattened strands remain sharp.
  • State the diamond direction on drawings for consistent panels.

Common Selection Mistakes with Flattened Expanded Metal

  • Expecting the stiffness of raised expanded metal.
  • Ordering the wrong diamond direction.

Where Flattened Expanded Metal Is Not the Right Choice

Not for walkways that need slip resistance — use raised expanded metal or grating.

If This Construction Is Not the Right Fit

Closely related mesh types for the same duty — compare open area, aperture range and cleanability before you commit.
