Vibrating Mesh Nebulizer Plate — ISO 27427 nebulizer designs
Vibrating Mesh Nebulizer Plate for generating inhalable aerosol in vibrating-mesh nebulizers by pushing liquid medication through thousands of micron-scale laser-drilled holes. 3 sizes listed, with technical drawing and quotation.
Customize the parameters below — every spec field is editable, and the drawing redraws to match the values you choose. Changing the size will snap the other fields to that size's standard values; you can then override any individual value.
Sends the selected values to the quote form below.
Request a Quotation for Vibrating Mesh Nebulizer Plate
Tell us the specification (mesh count / micron / dimensions), material and quantity you need for Vibrating Mesh Nebulizer Plate (ISO 27427 nebulizer designs) and our team will respond within one business day. Click "Request this configuration" on the drawing above to send the parameters you just chose straight into this form.
Dimensions & Specifications (ISO 27427 nebulizer designs)
Every row below is a starting point for the customizer above — pick any specification row and the drawing will redraw to it.
Size
Plate diameter (mm)
Thickness (mm)
Hole diameter (mm)
Hole count
Hole rings
MMAD (u00b5m)
N-3.0
8
0.05
0.0030
4000
7
3.0
N-4.0
8
0.05
0.0040
3000
6
4.0
N-5.0
10
0.06
0.0050
2500
6
5.0
Vibrating Mesh Nebulizer Plate (ISO 27427 nebulizer designs) is used for generating inhalable aerosol in vibrating-mesh nebulizers by pushing liquid medication through thousands of micron-scale laser-drilled holes.
Hole size: Sets droplet MMAD — about 3–5 µm for deep-lung delivery.
Plate diameter: Matches the piezo actuator and housing.
Material: Biocompatible stainless or palladium-nickel alloys.
Materials
Standard supply is stainless steel 316/316L; the material column in the table and the drawing options show the exact grade for each size. Other alloys and finishes can be quoted to your drawing.
Fitting & Care
Clean after every use per the device instructions.
Never touch or wipe the mesh.
Common Mistakes
Saline crystal buildup that blocks holes.
Using a mesh with the wrong MMAD.
When Vibrating Mesh Nebulizer Plate Is Not the Right Choice
Not for suspensions with large particles that cannot pass the holes.
Vibrating Mesh Nebulizer Plate is made to order as finished parts. Indicative pricing starts from about US$1.90 per piece for a standard size at production quantity; the final price depends on size, material, finish, tooling and order volume. Send your configuration from the drawing above for a quotation.
Vibrating Mesh Nebulizer Plate — ISO 27427 nebulizer designs
Generating inhalable aerosol in vibrating-mesh nebulizers by pushing liquid medication through thousands of micron-scale laser-drilled holes.
What is MMAD in nebulizers?
Mass median aerodynamic diameter — the droplet size that determines where medication deposits.
How are nebulizer mesh holes made?
By laser drilling or electroforming.
How long does a nebulizer mesh last?
Months with proper cleaning.
What is the specification range of Vibrating Mesh Nebulizer Plate?
The table on this page lists 3 standard specifications for Vibrating Mesh Nebulizer Plate, from N-3.0 to N-5.0. Specifications outside the table — custom mesh counts, wire diameters, roll widths and fabricated pieces — can be quoted on request.
How do I request a quotation?
Use the parametric drawing on this page to set the exact configuration (specification, material, treatment) and click "Request this configuration" — a specialist from custommetalfilters.com will respond within one business day.
Related Mesh Products
Closely related constructions in Laboratory & Medical Mesh — compare aperture range, open area and cleanability.
