Air Jet Sieve for measuring the fine fraction of powders below 100 µm on air jet sieving machines, where a rotating slit nozzle blows the powder off the sieve while a vacuum pulls the fines through. 4 sizes listed, with technical drawing and quotation.
Air Jet Sieve (ISO 3310-1 / DIN 66165) — Test Sieves
Technical Drawing
Customize the parameters below — every spec field is editable, and the drawing redraws to match the values you choose. Changing the size will snap the other fields to that size's standard values; you can then override any individual value.
Sends the selected values to the quote form below.
Request a Quotation for Air Jet Sieve
Tell us the specification (mesh count / micron / dimensions), material and quantity you need for Air Jet Sieve (ISO 3310-1 / DIN 66165) and our team will respond within one business day. Click "Request this configuration" on the drawing above to send the parameters you just chose straight into this form.
Dimensions & Specifications (ISO 3310-1 / DIN 66165)
Every row below is a starting point for the customizer above — pick any specification row and the drawing will redraw to it.
Aperture (mm)
Frame diameter (mm)
Frame height (mm)
Wire diameter (mm)
Mesh count
Frame
0.020
200
25
0.020
635-Mesh
SS304, air-jet seal
0.045
200
25
0.032
325-Mesh
SS304, air-jet seal
0.063
200
25
0.045
230-Mesh
SS304, air-jet seal
0.090
200
25
0.063
170-Mesh
SS304, air-jet seal
Air Jet Sieve (ISO 3310-1 / DIN 66165) is used for measuring the fine fraction of powders below 100 µm on air jet sieving machines, where a rotating slit nozzle blows the powder off the sieve while a vacuum pulls the fines through.
Frame: 200 mm frame with the air-jet sealing face that fits the machine.
Certificate: Inspection or calibration certificate for audited labs.
Materials
Standard supply is stainless steel 304; the material column in the table and the drawing options show the exact grade for each size. Other alloys and finishes can be quoted to your drawing.
Fitting & Care
Weigh samples precisely and run for the time set by the method.
Clean ultrasonically after use and dry flat.
Common Mistakes
Using a standard test sieve frame that does not seal on the air-jet machine.
Overloading the sieve with sample.
When Air Jet Sieve Is Not the Right Choice
Not for coarse samples above about 200 µm, where shaker sieving is quicker.
Air Jet Sieve is made to order as finished parts. Indicative pricing starts from about US$120.00 per piece for a standard size at production quantity; the final price depends on size, material, finish, tooling and order volume. Send your configuration from the drawing above for a quotation.
Measuring the fine fraction of powders below 100 µm on air jet sieving machines, where a rotating slit nozzle blows the powder off the sieve while a vacuum pulls the fines through.
What is an air jet sieve?
A test sieve used on an air-jet machine that blows powder clear while vacuum draws fines through.
Why use air jet sieving?
It is faster and more repeatable for fine powders than shaking.
What aperture range is typical?
About 20–90 µm.
What specifications are available for Air Jet Sieve?
The table on this page lists 4 standard specifications for Air Jet Sieve, from 0.020 to 0.090. Specifications outside the table — custom mesh counts, wire diameters, roll widths and fabricated pieces — can be quoted on request.
How do I request a quotation?
Use the parametric drawing on this page to set the exact configuration (specification, material, treatment) and click "Request this configuration" — a specialist from custommetalfilters.com will respond within one business day.
