Precious Metal Catalyst Trap Filter — ISO 4022 / ASME BPE
Precious Metal Catalyst Trap Filter for catching palladium, platinum and rhodium catalyst fines after hydrogenation and coupling reactions so the precious metal is recovered instead of lost to the product or waste stream. 3 sizes listed, with technical drawing and quotation.
Precious Metal Catalyst Trap Filter (ISO 4022 / ASME BPE) — Sintered Porous Metal Elements
Technical Drawing
Customize the parameters below — every spec field is editable, and the drawing redraws to match the values you choose. Changing the size will snap the other fields to that size's standard values; you can then override any individual value.
Sends the selected values to the quote form below.
Request a Quotation for Precious Metal Catalyst Trap Filter
Tell us the specification (mesh count / micron / dimensions), material and quantity you need for Precious Metal Catalyst Trap Filter (ISO 4022 / ASME BPE) and our team will respond within one business day. Click "Request this configuration" on the drawing above to send the parameters you just chose straight into this form.
Dimensions & Specifications (ISO 4022 / ASME BPE)
Every row below is a starting point for the customizer above — pick any specification row and the drawing will redraw to it.
Size
Outer diameter (mm)
Length (mm)
Micron rating (u00b5m)
Design pressure (bar)
Media
Lab 25
25
100
1
16
Sintered SS316L powder
Pilot 60
60
250
2
25
Sintered SS316L powder
Plant 60 u00d7 1000
60
1000
5
25
Sintered 5-layer SS316L mesh
Precious Metal Catalyst Trap Filter (ISO 4022 / ASME BPE) is used for catching palladium, platinum and rhodium catalyst fines after hydrogenation and coupling reactions so the precious metal is recovered instead of lost to the product or waste stream.
Also known as: precious metal catalyst trap filter, catalyst recovery filter, Pd/C filter
How to Specify Precious Metal Catalyst Trap Filter
Micron rating: 1–5 µm sintered media retains typical Pd/C fines.
Pressure & temperature: Match the reactor discharge conditions and the back-flush pressure.
Construction: All-welded SS316L with ASME BPE finishes where GMP cleaning is required.
Materials
Standard supply is stainless steel 316/316L; the material column in the table and the drawing options show the exact grade for each size. Other alloys and finishes can be quoted to your drawing.
Fitting & Care
Back-flush recovered catalyst into a closed, inerted receiver.
Keep palladium-on-carbon wet throughout; dry Pd/C can ignite solvents in air.
Common Mistakes
Allowing the cake to dry on the element, creating a fire risk at opening.
Undersizing filter area so the trap blinds within a single batch.
When Precious Metal Catalyst Trap Filter Is Not the Right Choice
Not designed for bulk solids separation or for low-value catalysts where disposable bag filters are cheaper.
Precious Metal Catalyst Trap Filter is made to order as finished parts. Indicative pricing starts from about US$260.00 per piece for a standard size at production quantity; the final price depends on size, material, finish, tooling and order volume. Send your configuration from the drawing above for a quotation.
Precious Metal Catalyst Trap Filter — ISO 4022 / ASME BPE
What is Precious Metal Catalyst Trap Filter used for?
Catching palladium, platinum and rhodium catalyst fines after hydrogenation and coupling reactions so the precious metal is recovered instead of lost to the product or waste stream.
Why install a precious metal catalyst trap filter?
Palladium and platinum are expensive; a trap recovers fines that would otherwise contaminate the product or be lost.
What micron rating catches Pd/C catalyst?
Typically 1–5 µm sintered media.
Can catalyst trap filters be reused?
Yes — the sintered element is back-flushed, cleaned and integrity-tested between campaigns.
Which specifications of Precious Metal Catalyst Trap Filter does custommetalfilters.com supply?
The table on this page lists 3 standard specifications for Precious Metal Catalyst Trap Filter, from Lab 25 to Plant 60 u00d7 1000. Specifications outside the table — custom mesh counts, wire diameters, roll widths and fabricated pieces — can be quoted on request.
How do I request a quotation?
Use the parametric drawing on this page to set the exact configuration (specification, material, treatment) and click "Request this configuration" — a specialist from custommetalfilters.com will respond within one business day.
