VCR Gasket Filter — Fits 1/4 in and 1/2 in face-seal fittings

Name: VCR Gasket Filter
Brand: custommetalfilters.com
SKU: EHM-DSC-06
Price: 9 USD
Availability: InStock

VCR Gasket Filter for filtering ultra-high-purity process gases inside the face-seal fitting itself, with a sintered metal disc built into the metal gasket — zero added length and no extra joints. 3 sizes listed, with technical drawing and quotation.

VCR Gasket Filter (Fits 1/4 in and 1/2 in face-seal fittings) — Sintered Porous Metal Elements

Technical Drawing

Customize the parameters below — every spec field is editable, and the drawing redraws to match the values you choose. Changing the size will snap the other fields to that size's standard values; you can then override any individual value.

Sends the selected values to the quote form below.

Request a Quotation for VCR Gasket Filter

Tell us the specification (mesh count / micron / dimensions), material and quantity you need for VCR Gasket Filter (Fits 1/4 in and 1/2 in face-seal fittings) and our team will respond within one business day. Click "Request this configuration" on the drawing above to send the parameters you just chose straight into this form.

Category Type Standard Mesh count / micron Material Finish

Dimensions & Specifications (Fits 1/4 in and 1/2 in face-seal fittings)

Every row below is a starting point for the customizer above — pick any specification row and the drawing will redraw to it.

Size	Diameter (mm)	Micron rating (u00b5m)	Gasket material	Fitting
1/4 in	10.8	0.5	SS316L	1/4 in face seal
1/4 in Ni	10.8	2	Nickel 200	1/4 in face seal
1/2 in	17.5	5	SS316L	1/2 in face seal

VCR Gasket Filter (Fits 1/4 in and 1/2 in face-seal fittings) is used for filtering ultra-high-purity process gases inside the face-seal fitting itself, with a sintered metal disc built into the metal gasket — zero added length and no extra joints.

Made by: Sintered Media (Diffusion Bonding) · Filter Fabrication & Assembly

Where VCR Gasket Filter Is Used

Semiconductor fabs: point-of-use protection on gas sticks and tool inlets.
Analytical instruments: carrier and calibration gas lines in GC and mass spec.
Specialty gas suppliers: cylinder valve outlets.
Vacuum & research systems: particle barriers between components.

Read the full application guide for VCR Gasket Filter →

How to Specify VCR Gasket Filter

Fitting size: Matches 1/4 in or 1/2 in face-seal glands.
Rating: 0.5–5 µm sintered media; finer ratings cost flow.
Gasket material: SS316L for general gases, nickel for corrosive or high-purity service.

Materials

Standard supply is stainless steel 316/316L; the material column in the table and the drawing options show the exact grade for each size. Other alloys and finishes can be quoted to your drawing.

Fitting & Care

Use each gasket filter once — the gasket bead deforms when the fitting is made up.
Install in clean conditions, with gloves, and helium leak-test the joint.

Common Mistakes

Re-using a gasket filter, which leaks.
Choosing a 0.5 µm filter where flow is critical.

When VCR Gasket Filter Is Not the Right Choice

Not designed for high dirt loads; inline filter housings take more contamination.

Related Mesh Products

Pricing

VCR Gasket Filter is made to order as finished parts. Indicative pricing starts from about US$9.00 per piece for a standard size at production quantity; the final price depends on size, material, finish, tooling and order volume. Send your configuration from the drawing above for a quotation.

Frequently Asked Questions

What is VCR Gasket Filter used for?

Filtering ultra-high-purity process gases inside the face-seal fitting itself, with a sintered metal disc built into the metal gasket — zero added length and no extra joints.

What is a gasket filter?

A face-seal gasket with a sintered metal filter disc in its center.

Can gasket filters be reused?

No — like any face-seal gasket they are single use.

What ratings do gasket filters have?

Typically 0.5 to 5 µm.

Which specifications of VCR Gasket Filter does custommetalfilters.com supply?

The table on this page lists 3 standard specifications for VCR Gasket Filter, from 1/4 in to 1/2 in. Specifications outside the table — custom mesh counts, wire diameters, roll widths and fabricated pieces — can be quoted on request.

How do I request a quotation?

Use the parametric drawing on this page to set the exact configuration (specification, material, treatment) and click "Request this configuration" — a specialist from custommetalfilters.com will respond within one business day.
