Moka Pot Filter Plate & Funnel — FDA 21 CFR / EU 1935/2004 food contact
Moka Pot Filter Plate & Funnel for holding ground coffee in a stovetop moka pot: a perforated funnel basket carries the grounds and a gasketed filter plate above keeps them out of the brewed coffee. 4 sizes listed, with technical drawing and quotation.
Moka Pot Filter Plate & Funnel (FDA 21 CFR / EU 1935/2004 food contact) — Coffee Filters
Technical Drawing
Customize the parameters below — every spec field is editable, and the drawing redraws to match the values you choose. Changing the size will snap the other fields to that size's standard values; you can then override any individual value.
Sends the selected values to the quote form below.
Request a Quotation for Moka Pot Filter Plate & Funnel
Tell us the specification (mesh count / micron / dimensions), material and quantity you need for Moka Pot Filter Plate & Funnel (FDA 21 CFR / EU 1935/2004 food contact) and our team will respond within one business day. Click "Request this configuration" on the drawing above to send the parameters you just chose straight into this form.
Every row below is a starting point for the customizer above — pick any specification row and the drawing will redraw to it.
Size
Plate diameter (mm)
Thickness (mm)
Hole diameter (mm)
Hole count
Hole rings
Funnel capacity (g)
1 cup
41
0.6
0.60
85
4
6
3 cup
52
0.6
0.60
120
5
15
6 cup
62
0.8
0.70
170
5
30
9 cup
70
0.8
0.70
210
6
45
Moka Pot Filter Plate & Funnel (FDA 21 CFR / EU 1935/2004 food contact) is used for holding ground coffee in a stovetop moka pot: a perforated funnel basket carries the grounds and a gasketed filter plate above keeps them out of the brewed coffee.
Cup size: Match the pot: 1, 3, 6 or 9 cup; funnel capacity follows.
Holes: 0.6–0.7 mm holes hold back a fine-medium grind.
Material: SS304 for induction-ready and dishwasher-safe pots; aluminum for classic pots.
Materials
Standard supply is stainless steel 304; the material column in the table and the drawing options show the exact grade for each size. Other alloys and finishes can be quoted to your drawing.
Fitting & Care
Fill the funnel level without tamping, so pressure stays safe.
Rinse after use and replace the gasket when it hardens.
Common Mistakes
Ordering by cup size of a different brand, which may not fit.
Tamping or using espresso-fine coffee, which over-pressurizes the pot.
When Moka Pot Filter Plate & Funnel Is Not the Right Choice
Not an espresso basket — moka pots brew at about 1–1.5 bar, not 9 bar.
Moka Pot Filter Plate & Funnel is made to order as finished parts. Indicative pricing starts from about US$0.90 per piece for a standard size at production quantity; the final price depends on size, material, finish, tooling and order volume. Send your configuration from the drawing above for a quotation.
Moka Pot Filter Plate & Funnel — FDA 21 CFR / EU 1935/2004 food contact
Holding ground coffee in a stovetop moka pot: a perforated funnel basket carries the grounds and a gasketed filter plate above keeps them out of the brewed coffee.
Can I replace a moka pot filter plate?
Yes — plates and funnels are sold by cup size.
Stainless or aluminum moka parts?
Stainless works on induction and resists corrosion.
What grind for a moka pot?
Fine-medium, slightly coarser than espresso.
What specifications are available for Moka Pot Filter Plate & Funnel?
The table on this page lists 4 standard specifications for Moka Pot Filter Plate & Funnel, from 1 cup to 9 cup. Specifications outside the table — custom mesh counts, wire diameters, roll widths and fabricated pieces — can be quoted on request.
How do I request a quotation?
Use the parametric drawing on this page to set the exact configuration (specification, material, treatment) and click "Request this configuration" — a specialist from custommetalfilters.com will respond within one business day.
