Oil Well Sand Control Screen — API RP 19C / ISO 17824
Oil Well Sand Control Screen for keeping formation sand out of oil and gas production with premium sintered-mesh or wire-wrap screens built on perforated base pipe. 3 sizes listed, with technical drawing and quotation.
Oil Well Sand Control Screen (API RP 19C / ISO 17824) — Oilfield Screens
Technical Drawing
Customize the parameters below — every spec field is editable, and the drawing redraws to match the values you choose. Changing the size will snap the other fields to that size's standard values; you can then override any individual value.
Sends the selected values to the quote form below.
Request a Quotation for Oil Well Sand Control Screen
Tell us the specification (mesh count / micron / dimensions), material and quantity you need for Oil Well Sand Control Screen (API RP 19C / ISO 17824) and our team will respond within one business day. Click "Request this configuration" on the drawing above to send the parameters you just chose straight into this form.
Dimensions & Specifications (API RP 19C / ISO 17824)
Every row below is a starting point for the customizer above — pick any specification row and the drawing will redraw to it.
Size
Outer diameter (mm)
Length (mm)
Micron rating (u00b5m)
Construction
2 7/8 in
89
6000
150
Premium sintered mesh
4 1/2 in
135
12000
200
Premium sintered mesh
5 1/2 in
160
12000
250
Wire-wrap
Oil Well Sand Control Screen (API RP 19C / ISO 17824) is used for keeping formation sand out of oil and gas production with premium sintered-mesh or wire-wrap screens built on perforated base pipe.
Base pipe: 2 7/8 to 5 1/2 in, with connection and grade.
Rating: 150–250 µm chosen from formation sand analysis.
Construction: Premium multi-layer mesh with protective shroud, or wire-wrap.
Materials
Standard supply is stainless steel 316/316L; the material column in the table and the drawing options show the exact grade for each size. Other alloys and finishes can be quoted to your drawing.
Fitting & Care
Handle joints with care to avoid denting the shroud.
Size the rating from a laboratory sand retention test.
Common Mistakes
Choosing a rating without sand analysis.
Damaging screens on the rig floor.
When Oil Well Sand Control Screen Is Not the Right Choice
Oil Well Sand Control Screen is made to order as finished parts. Indicative pricing starts from about US$950.00 per piece for a standard size at production quantity; the final price depends on size, material, finish, tooling and order volume. Send your configuration from the drawing above for a quotation.
Oil Well Sand Control Screen — API RP 19C / ISO 17824
Keeping formation sand out of oil and gas production with premium sintered-mesh or wire-wrap screens built on perforated base pipe.
What is a sand control screen?
A downhole screen that holds back formation sand while oil and gas flow in.
What is a premium mesh screen?
A screen with sintered multi-layer mesh under a protective shroud.
How is the rating chosen?
From formation sand analysis.
Which specifications of Oil Well Sand Control Screen does custommetalfilters.com supply?
The table on this page lists 3 standard specifications for Oil Well Sand Control Screen, from 2 7/8 in to 5 1/2 in. Specifications outside the table — custom mesh counts, wire diameters, roll widths and fabricated pieces — can be quoted on request.
How do I request a quotation?
Use the parametric drawing on this page to set the exact configuration (specification, material, treatment) and click "Request this configuration" — a specialist from custommetalfilters.com will respond within one business day.
