Industrial Wire Mesh Basket — Custom to drawing (DIN 1/1 tray grid)
Industrial Wire Mesh Basket for holding machined, stamped and cast parts through washing, degreasing, heat treatment, dip coating and storage in welded wire or expanded metal baskets built to the line. 5 sizes listed, with technical drawing and quotation.
Industrial Wire Mesh Basket (Custom to drawing (DIN 1/1 tray grid)) — Wire Mesh Baskets
Technical Drawing
Customize the parameters below — every spec field is editable, and the drawing redraws to match the values you choose. Changing the size will snap the other fields to that size's standard values; you can then override any individual value.
Sends the selected values to the quote form below.
Request a Quotation for Industrial Wire Mesh Basket
Tell us the specification (mesh count / micron / dimensions), material and quantity you need for Industrial Wire Mesh Basket (Custom to drawing (DIN 1/1 tray grid)) and our team will respond within one business day. Click "Request this configuration" on the drawing above to send the parameters you just chose straight into this form.
Dimensions & Specifications (Custom to drawing (DIN 1/1 tray grid))
Every row below is a starting point for the customizer above — pick any specification row and the drawing will redraw to it.
Size
Length (mm)
Width (mm)
Height (mm)
Mesh opening (mm)
Wire diameter (mm)
Parts washing 600
600
400
200
6
1.6
Heat treat 500
500
500
300
12
3.0
Ultrasonic 300
300
200
100
3
1.0
Expanded metal 600
600
400
150
10
1.5
Dip / coating 400
400
300
250
8
2.0
Industrial Wire Mesh Basket (Custom to drawing (DIN 1/1 tray grid)) is used for holding machined, stamped and cast parts through washing, degreasing, heat treatment, dip coating and storage in welded wire or expanded metal baskets built to the line.
Also known as: metal mesh basket, wire mesh basket, expanded metal basket, parts washing basket, heat treatment basket
Size & load: Give inner dimensions, stacking height and maximum payload at operating temperature.
Mesh & wire: Opening smaller than the smallest part; heavier wire and frame rods for furnace work.
Alloy: SS304 for washing to 800 °C; 310S or Inconel 600 for furnaces above 900 °C.
Materials
Standard supply is stainless steel 304, Inconel 600; the material column in the table and the drawing options show the exact grade for each size. Other alloys and finishes can be quoted to your drawing.
Fitting & Care
Load heat-treat baskets evenly and below the rated hot load; strength falls sharply with temperature.
Inspect welds and corners regularly — cracked joints release parts into the washer or quench tank.
Common Mistakes
Choosing a mesh opening larger than small fasteners or pins, which fall through.
Running SS304 baskets above 900 °C, where they scale and distort quickly.
When Industrial Wire Mesh Basket Is Not the Right Choice
Not a medical sterilization basket — those need electropolished DIN-size trays.
Industrial Wire Mesh Basket is made to order as finished parts. Indicative pricing starts from about US$22.00 per piece for a standard size at production quantity; the final price depends on size, material, finish, tooling and order volume. Send your configuration from the drawing above for a quotation.
Industrial Wire Mesh Basket — Custom to drawing (DIN 1/1 tray grid)
Holding machined, stamped and cast parts through washing, degreasing, heat treatment, dip coating and storage in welded wire or expanded metal baskets built to the line.
What are industrial wire mesh baskets used for?
Washing, degreasing, heat treatment, coating and handling parts.
Which alloy is best for heat-treat baskets?
310S stainless or Inconel 600 for furnace temperatures above about 900 °C.
Can wire mesh baskets be made to custom sizes?
Yes — they are built to the drawing of your washer, furnace or rack.
Which specifications of Industrial Wire Mesh Basket does custommetalfilters.com supply?
The table on this page lists 5 standard specifications for Industrial Wire Mesh Basket, from Parts washing 600 to Dip / coating 400. Specifications outside the table — custom mesh counts, wire diameters, roll widths and fabricated pieces — can be quoted on request.
How do I request a quotation?
Use the parametric drawing on this page to set the exact configuration (specification, material, treatment) and click "Request this configuration" — a specialist from custommetalfilters.com will respond within one business day.
Related Mesh Products
Closely related constructions in Welded Wire Mesh — compare aperture range, open area and cleanability.
