Fruit & Juice Press Filter Screen — FDA 21 CFR / EU 1935/2004 food contact
Fruit & Juice Press Filter Screen for separating juice from pomace in belt presses, hydraulic basket presses and cider racks with perforated stainless screens that resist acid and constant pressing loads. 4 sizes listed, with technical drawing and quotation.
Fruit & Juice Press Filter Screen (FDA 21 CFR / EU 1935/2004 food contact) — Juicing, Pulping & Washing
Technical Drawing
Customize the parameters below — every spec field is editable, and the drawing redraws to match the values you choose. Changing the size will snap the other fields to that size's standard values; you can then override any individual value.
Sends the selected values to the quote form below.
Request a Quotation for Fruit & Juice Press Filter Screen
Tell us the specification (mesh count / micron / dimensions), material and quantity you need for Fruit & Juice Press Filter Screen (FDA 21 CFR / EU 1935/2004 food contact) and our team will respond within one business day. Click "Request this configuration" on the drawing above to send the parameters you just chose straight into this form.
Every row below is a starting point for the customizer above — pick any specification row and the drawing will redraw to it.
Size
Hole diameter (mm)
Pitch (mm)
Thickness (mm)
Open area (%)
Use
u00d80.8 / P1.6
0.8
1.6
0.8
22.7
Belt press screen
u00d81.0 / P2.0
1.0
2.0
1.0
22.7
Hydraulic press basket
u00d81.5 / P2.5
1.5
2.5
1.0
32.6
Cider press rack
u00d80.5 / P1.0
0.5
1.0
0.6
22.7
Citrus extractor strainer
Fruit & Juice Press Filter Screen (FDA 21 CFR / EU 1935/2004 food contact) is used for separating juice from pomace in belt presses, hydraulic basket presses and cider racks with perforated stainless screens that resist acid and constant pressing loads.
Hole size: 0.5–1.5 mm: finer for clearer juice, coarser for higher throughput and less blinding.
Thickness & support: Plate thickness and backing for the press force.
Alloy: SS316 resists fruit acids and cleaning chemicals.
Materials
Standard supply is stainless steel 304, stainless steel 316/316L; the material column in the table and the drawing options show the exact grade for each size. Other alloys and finishes can be quoted to your drawing.
Fitting & Care
Clean immediately after pressing; dried pectin and sugar are hard to remove.
Inspect for cracked holes or worn edges at season start.
Common Mistakes
Choosing holes so fine they blind with pulp.
Using SS304 with acidic citrus.
When Fruit & Juice Press Filter Screen Is Not the Right Choice
Not a final clarification filter — juice still needs centrifuging or fine filtration.
Fruit & Juice Press Filter Screen is made to order as finished parts. Indicative pricing starts from about US$38.00 per piece for a standard size at production quantity; the final price depends on size, material, finish, tooling and order volume. Send your configuration from the drawing above for a quotation.
Fruit & Juice Press Filter Screen — FDA 21 CFR / EU 1935/2004 food contact
What is Fruit & Juice Press Filter Screen used for?
Separating juice from pomace in belt presses, hydraulic basket presses and cider racks with perforated stainless screens that resist acid and constant pressing loads.
What screen is used in fruit presses?
Perforated stainless plates or baskets with 0.5–1.5 mm holes.
Which stainless for juice presses?
SS316 for acidic fruit.
How do I clean press screens?
Rinse immediately, then CIP or soak in alkaline cleaner.
Which specifications of Fruit & Juice Press Filter Screen does custommetalfilters.com supply?
The table on this page lists 4 standard specifications for Fruit & Juice Press Filter Screen, from u00d80.8 / P1.6 to u00d80.5 / P1.0. Specifications outside the table — custom mesh counts, wire diameters, roll widths and fabricated pieces — can be quoted on request.
How do I request a quotation?
Use the parametric drawing on this page to set the exact configuration (specification, material, treatment) and click "Request this configuration" — a specialist from custommetalfilters.com will respond within one business day.
