Smartwatch & Wearable Vent Mesh for protecting the speaker, buzzer, barometric pressure and microphone ports of smartwatches and fitness wearables from sweat, sand and water. 3 sizes listed, with technical drawing and quotation.
Customize the parameters below — every spec field is editable, and the drawing redraws to match the values you choose. Changing the size will snap the other fields to that size's standard values; you can then override any individual value.
Sends the selected values to the quote form below.
Request a Quotation for Smartwatch & Wearable Vent Mesh
Tell us the specification (mesh count / micron / dimensions), material and quantity you need for Smartwatch & Wearable Vent Mesh (IEC 60529 IP68 / ISO 22810) and our team will respond within one business day. Click "Request this configuration" on the drawing above to send the parameters you just chose straight into this form.
Dimensions & Specifications (IEC 60529 IP68 / ISO 22810)
Every row below is a starting point for the customizer above — pick any specification row and the drawing will redraw to it.
Part
Length (mm)
Width (mm)
Thickness (mm)
Hole diameter (mm)
Open area (%)
Function
Speaker vent
8.0
1.2
0.05
0.035
18
Speaker / buzzer
Barometer port
2.5
2.5
0.04
0.025
12
Pressure equalizing
Mic port
1.8
1.8
0.04
0.030
15
Microphone
Smartwatch & Wearable Vent Mesh (IEC 60529 IP68 / ISO 22810) is used for protecting the speaker, buzzer, barometric pressure and microphone ports of smartwatches and fitness wearables from sweat, sand and water.
Corrosion resistance: Use SS316L — sweat chlorides pit 304 mesh within months.
Pressure response: Barometer ports need low-resistance mesh so readings follow altitude changes without lag.
Size & thickness: Slots can be under 1.5 mm wide; 0.04–0.05 mm mesh keeps the stack thin.
Materials
Standard supply is stainless steel 316/316L; the material column in the table and the drawing options show the exact grade for each size. Other alloys and finishes can be quoted to your drawing.
Fitting & Care
Bond meshes inside the case before the membrane and gasket, using adhesive rated for sweat and sunscreen exposure.
Advise users to rinse the watch in fresh water after the sea, pool or heavy sweating.
Common Mistakes
Putting a high-Rayl mesh on the barometer port, which delays altitude and depth readings.
Using 304 stainless in a product worn during exercise.
When Smartwatch & Wearable Vent Mesh Is Not the Right Choice
Not by itself a water seal — water resistance ratings come from the membrane and gaskets behind the mesh.
Smartwatch & Wearable Vent Mesh is made to order as finished parts. Indicative pricing starts from about US$0.050 per piece for a standard size at production quantity; the final price depends on size, material, finish, tooling and order volume. Send your configuration from the drawing above for a quotation.
Protecting the speaker, buzzer, barometric pressure and microphone ports of smartwatches and fitness wearables from sweat, sand and water.
Why should I rinse my smartwatch after swimming?
Salt and chlorine dry as crystals in the port meshes and can muffle the speaker or slow the pressure sensor.
Which stainless steel is used in wearable meshes?
316L, because it resists sweat chlorides far better than 304.
Can a vent mesh affect altitude readings?
Yes, if its acoustic and air resistance is too high; barometer ports use a more open mesh.
What specifications are available for Smartwatch & Wearable Vent Mesh?
The table on this page lists 3 standard specifications for Smartwatch & Wearable Vent Mesh, from Speaker vent to Mic port. Specifications outside the table — custom mesh counts, wire diameters, roll widths and fabricated pieces — can be quoted on request.
How do I request a quotation?
Use the parametric drawing on this page to set the exact configuration (specification, material, treatment) and click "Request this configuration" — a specialist from custommetalfilters.com will respond within one business day.
