Faucet Aerator Mesh Insert — ASME A112.18.1 / EN 246
Faucet Aerator Mesh Insert for mixing air into tap water and breaking the stream into a soft, non-splashing jet through stacked stainless mesh discs. 4 sizes listed, with technical drawing and quotation.
Customize the parameters below — every spec field is editable, and the drawing redraws to match the values you choose. Changing the size will snap the other fields to that size's standard values; you can then override any individual value.
Sends the selected values to the quote form below.
Request a Quotation for Faucet Aerator Mesh Insert
Tell us the specification (mesh count / micron / dimensions), material and quantity you need for Faucet Aerator Mesh Insert (ASME A112.18.1 / EN 246) and our team will respond within one business day. Click "Request this configuration" on the drawing above to send the parameters you just chose straight into this form.
Dimensions & Specifications (ASME A112.18.1 / EN 246)
Every row below is a starting point for the customizer above — pick any specification row and the drawing will redraw to it.
Size
Diameter (mm)
Layers
Mesh
Flow (L/min)
Thread
M22 female
18.5
3
40 / 60 / 40-Mesh
6
M22 u00d7 1
M24 male
20.5
3
40 / 60 / 40-Mesh
6
M24 u00d7 1
M28 male
24.0
3
40 / 60 / 40-Mesh
8
M28 u00d7 1
Tiny M16.5
13.5
2
60-Mesh
4
M16.5 u00d7 0.75
Faucet Aerator Mesh Insert (ASME A112.18.1 / EN 246) is used for mixing air into tap water and breaking the stream into a soft, non-splashing jet through stacked stainless mesh discs.
Thread: M22 × 1 female or M24 × 1 male for most taps.
Flow class: 4–8 L/min set by the restrictor.
Layers: Three stacked discs for a fully aerated stream.
Materials
Standard supply is stainless steel 304, brass; the material column in the table and the drawing options show the exact grade for each size. Other alloys and finishes can be quoted to your drawing.
Fitting & Care
Unscrew the aerator and rinse the discs when the stream becomes uneven.
Wrap the wrench jaws in cloth to protect plated finishes.
Common Mistakes
Mixing up M22 and M24 sizes.
Removing mesh layers to increase flow, which causes splashing.
When Faucet Aerator Mesh Insert Is Not the Right Choice
Not for sediment-heavy well water without an upstream filter.
Faucet Aerator Mesh Insert is made to order as finished parts. Indicative pricing starts from about US$0.080 per piece for a standard size at production quantity; the final price depends on size, material, finish, tooling and order volume. Send your configuration from the drawing above for a quotation.
Faucet Aerator Mesh Insert — ASME A112.18.1 / EN 246
Mixing air into tap water and breaking the stream into a soft, non-splashing jet through stacked stainless mesh discs.
What does a faucet aerator do?
It adds air to the water stream for a soft, non-splashing flow and lower water use.
How do I know my aerator size?
Thread inside the spout means an M24 male aerator; thread outside means M22 female.
Why is my tap spraying sideways?
Debris on the aerator mesh — clean or replace it.
Which specifications of Faucet Aerator Mesh Insert does custommetalfilters.com supply?
The table on this page lists 4 standard specifications for Faucet Aerator Mesh Insert, from M22 female to Tiny M16.5. Specifications outside the table — custom mesh counts, wire diameters, roll widths and fabricated pieces — can be quoted on request.
How do I request a quotation?
Use the parametric drawing on this page to set the exact configuration (specification, material, treatment) and click "Request this configuration" — a specialist from custommetalfilters.com will respond within one business day.
